Moeller Z00-10 Thermal Overload Relay
New
In stock1 unitReady to ship
MOELLER Thermal Overload Relay Z00-10
Reliable relay for 6-10 A, 690 V AC with short-circuit protection, 1 NO + 1 NC contacts, and M4 screw terminals.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
MOELLER Thermal Overload Relay Z00-10
The MOELLER Z00-10 Thermal Overload Relay is a dependable solution for motor protection, ensuring optimal safety and reliability in industrial applications. Designed for a current range of 6-10 A and rated for 690 V AC, it provides efficient short-circuit protection through fuses or circuit breakers. With auxiliary contacts and robust construction, it is ideal for demanding environments.
- Manufacturer: MOELLER
- Type: Thermal Overload Relay
- Model: Z00-10
- Rated Operational Voltage (Ue): 690 V AC
- Rated Impulse Withstand Voltage (Uimp): 6000 V AC
- Current Range: 6-10 A
- Auxiliary Contacts: 1 Normally Open (NO), 1 Normally Closed (NC)
- Short Circuit Protection:
- By Fuses: Max. 600 V AC
- By Circuit Breaker: Max. 600 V AC
- Terminal Screws: M4
- Tightening Torque: 1.8 Nm
- Ambient Temperature: 20 °C
- Dimensions (H X W X D): 85 x 90 x 45 mm
