Moog D633-313B Direct Drive Analog Control Servo Valve

Name: MOOG D633-313B DIRECT DRIVE ANALOG CONTROL SERVO VALVE
SKU: 994349
Price: 1990.00 USD
Availability: InStock

moog-d633-313b-direct-drive-analog-control-servo-valve-3

moog-d633-313b-direct-drive-analog-control-servo-valve-2

moog-d633-313b-direct-drive-analog-control-servo-valve-1

New

In stock1 unitReady to ship

1 990,00$

Manufacturer

MOOG

SKU

994349

Category

Servo Valves

Condition

New

Analog Control Direct Drive Hydraulic Moog Servo Valve valves

Massive Inventory

Global Shipping

Expert Support

Quality Guaranteed

Manufacturer: MOOG

Type: Direct Drive Analog Control Servo Valve

Model: D633-313B

Type Designation: R16KO1M0NSM2

Size: 03

Ambient Temperature Range: -20……+60 ^oC

Max. Operating Pressure Port P, A, B: 350 bar

Max. Operating Pressure Port T Without Y: 50 bar

Max. Operating Pressure Port T With Y: 350 bar

Maximum Flow: 75 l/min

Temperature Range: -20……+80 ^oC

Supply Voltage: 24V DC

Signal: +/- 10 V

Weight: 2.60 kg
