Murr 85460 Buffer Module
Murr Elektronik Buffer Module MB CAP ULTRA 3/24 1A/21S provides reliable buffering with 1A@21s capacity, 24 V DC input, and 23.3 V DC output. Designed for industrial applications with a protection degree of IP20 and operating temperature range of -20 to 60°C.
Murr Elektronik Buffer Module MB CAP ULTRA 3/24 1A/21S
Murr Elektronik Buffer Module MB CAP ULTRA 3/24 1A/21S is designed to provide stable and reliable buffering capabilities for industrial applications. It ensures a constant power supply and smooth operation under varying load conditions. This module is ideal for applications requiring a reliable backup power source and is engineered for optimal performance in harsh environments.
- Manufacturer: Murr Elektronik
- Type: Buffer Module
- Model: MB CAP ULTRA 3/24 1A/21S
- Art No.: 85460
Input:
- Voltage: 24 V DC (20.4 to 26.4 V DC max.)
- Current (charging): 3 A
- Charging Time: min. 25s
- Current (Buffering): 30 mA
Output:
- Voltage: 23.3 V DC
- Current: 0 to 3 A
- Capacity (Buffering): 1A@21s, 23.3 V DC
Other Specifications:
- Protection Degree: IP20
- Operating Temperature: -20 to 60 degrees Celsius
- Dimensions: 125 x 60 x 100 mm
