Nachi 51107G Thrust Ball Bearing

Manufacturer: NACHI

Type: Single-direction Thrust Ball Bearings

Model: 51107G

Dimensions

Bore diameter d: 35 mm

Outer diameter D: 52 mm

Height T: 12 mm

Outside diameter shaft washer d₁: 52 mm

Inner diameter housing washer D₁: 37 mm

Minimum chamfer dimension r_{s min}: 0.6 mm

Basic load ratings:

Dynamic C_a: 20400 N

Static C_0a: 44500 N

Allowable speed:

Grease lubrication: 4000 rpm

Oil lubrication: 6000 rpm
