Neugart PLFN064-025-RSSE3AD-Z8/25/30/46/B5/M4 Planetary Gearbox

Name: NEUGART PLFN064-025-RSSE3AD-Z8/25/30/46/B5/M4 PLANETARY GEARBOX
SKU: 1096939
Availability: LimitedAvailability

neugart-PLFN064-025-RSSE3AD-Z8253046B5M4-right-angle-gearbox(new)

neugart-PLFN064-025-RSSE3AD-Z8253046B5M4-right-angle-gearbox(new)-1

neugart-PLFN064-025-RSSE3AD-Z8253046B5M4-right-angle-gearbox(new)-2

neugart-PLFN064-025-RSSE3AD-Z8253046B5M4-right-angle-gearbox(new)-3

neugart-PLFN064-025-RSSE3AD-Z8253046B5M4-right-angle-gearbox(new)-4

New

In stock1 unitReady to ship

Planetary Gearbox NEUGART PLFN064-025-RSSE3AD precision planetary gearbox with 25:1 ratio, 2-stage construction, low backlash, IP65 protection and high torsional stiffness for servo and automation applications. Frame Size: 64 Ratio: 25 Protection Class: IP65 Standard Backlash: 3 – 5 arcmin Reduced Backlash: 2 arcmin Running Noise: 60 dB(A)

Manufacturer

NEUGART

SKU

1096939

Category

Servo Gearboxes

Condition

New

Automation Backlash Control Gear Gearbox Industrial low Motion Neugart Planetary PLE PLF Precision Reducer Series Servo Single Stage Transmission

Massive Inventory

Global Shipping

Expert Support

Quality Guaranteed

Series	PLF
Art-No.	100680301
F-No.	2440183-2-002
Frame Size	64
Number of Stage	2
Ratio	25
Shaft [mm]	20-40
Hollow Shaft [mm]	8
Flange Diameter [mm]	70
operating temperature	-25 / 90 °C
Protection class	IP65
Standard backlash	3 - 5 arcmin
Reduced backlash	2 arcmin
Torsional stiffness	7.6 - 14.8 Nm /arcmin
Gearbox weight	1.3 - 1.9 kg
Running noise	60 dB(A)
Stock Key	JO-004
Condition	New
SKU	1096939
Weight	2
