NTN / JBS 1220 Self-Aligning Ball Bearing
New
In stock1 unitReady to ship
SELF-ALIGNING BALL BEARING
NTN / JBS 1220 Self-Aligning Ball Bearing with 100 mm bore, 180 mm outer diameter, and 34 mm width. Features high load capacity, misalignment tolerance, and speeds up to 4800 tr/min.1001220180BallbearingboreCapacitydiameterHighIndustrialJBSLoadMisalignmentmmNTNOuterPrecisionSelf-AligningTolerant
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
NTN / JBS 1220 SELF-ALIGNING BALL BEARING
The NTN / JBS 1220 Self-Aligning Ball Bearing is designed to accommodate misalignment and shaft deflection, providing smooth operation under varying conditions. Built for durability and high load capacity, it is ideal for demanding industrial applications.
Manufacturer: NTN / JBS
Type: Self-Aligning Ball Bearing
Model: 1220
| Bore Diameter (d) | 100 mm |
| Outer Diameter (D) | 180 mm |
| Width (B) | 34 mm |
| Basic Dynamic Load Rating | 68,4 kN |
| Basic Static Load Rating | 29,7 kN |
| Fatigue Limit Load | 1,14 kN |
| Reference Thermal Speed | 4600 tr/min |
| Mechanical Limit Speed | 4800 tr/min |
