NTN NATR10LL/3AS Yoke Type Track Roller
New
In stock20 unitsReady to ship
15,55$
Yoke Type Track Roller
NTN NATR10LL/3AS Yoke Type Track Roller offers a 10 mm bore diameter and 30 mm outer diameter. It features dynamic and static load capacities of 7.85 kN and 9.65 kN, and operates at up to 10,000 tr/min with grease lubrication.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
NTN NATR10LL/3AS Yoke Type Track Roller
The NTN Yoke Type Track Roller NATR10LL/3AS is engineered for high-load applications, featuring a spherical outer ring and rubber sealing for reliable lubrication and performance in demanding environments.
Manufacturer: NTN
Type: Yoke Type Track Roller
Model: NATR10LL/3AS
| Bore Diameter (d) | 10 mm |
| Outer Diameter (D) | 30 mm |
| Width, Inner Ring (B) | 15 mm |
| Dynamic Load Capacity (Cr) | 7.85 kN |
| Static Load Capacity (C0r) | 9.65 kN |
| Track Load Capacity (Spherical Outer Ring) | 2.62 kN |
| Grease Lubrication Limit Speed | 10,000 tr/min |
| Sealing | LL, Rubber on Both Sides |
| Lubricant | 3A, Shell Oil Alvania #3 Grease |
