Omron F3S-TGR-CL2A-K4-900 Safety Light Guard
OMRON F3S-TGR-CL2A-K4-900 Safety Light Guard, 0.5 to 40 m sensing range, 900 mm protection height, 24 V DC, IP65-rated, reliable industrial safety device.
OMRON F3S-TGR-CL2A-K4-900 Safety Light Guard
The OMRON F3S-TGR-CL2A-K4-900 is a high-performance safety light guard designed to protect personnel and equipment in industrial environments. With an extensive sensing range of 0.5 to 40 meters, a 900 mm protection height, and a resolution of 30 mm, this safety device ensures precise detection and reliable protection. Its painted aluminum housing (yellow, RAL 1018) offers durability and compliance with IP65 standards for harsh environments.
🔧 Technical Specifications:
- Manufacturer: OMRON
- Type: Safety Light Guard
- Model: F3S-TGR-CL2A-K4-900
- Part No.: 632027/632227
- Sensing Range: 0.5 to 40 m
- Detection Capability: 300 mm
- System: Active/Active
- Protection Height: 900 mm
- Resolution: 30 mm
- Supply Voltage: 24 V DC
- Power Consumption Max.: 10 W
- OSSD: 2 PNP Transistor Output
- Response Time: 13 ms
- Connection: Connector 8-Pin
- Housing Material: Painted Aluminum, Yellow, RAL 1018
- Protection Class: IP65
- Operating Temperature: -10 to 55 °C
- Dimensions: 952 x 37 x 48 mm
The F3S-TGR-CL2A-K4-900 is an essential safety solution for industrial automation systems, ensuring maximum reliability and compliance with safety standards.
