Pepperl Fuchs 3RG4023-3CD00-PF Inductive Sensor

Manufacturer: Pepperl+Fuchs

Type: Inductive Proximity Switch

Model: 3RG4023-3CD00-PF

Part No: 552893

Rated Operating Distance: 8 mm

Assured Operating Distance: 6.48 mm

Operating Voltage: 15 … 34 V DC

Switching Current: ≤ 200 mA

No-Load Supply Current I₀: ≤ 17 mA

Voltage Drop U_d: ≤ 2.5 V

Signal Output: PNP

Switching Function: Normally Open and Normally Closed

Switching Frequency f: 300 Hz

Protection Degree: IP67

Ambient Temperature: -25 … 85 °C

Housing Material: Brass / Messing

Connection: Connector M12 x 1 , 4-pin

Diameter, Length: 18, 69 mm

Weight: 0.05 kg
