Pepperl+Fuchs NJ20+U1+W3 Inductive Sensor
Used
In stock1 unitReady to ship
Inductive Sensor
A durable and long-range inductive sensor from the VariKont family, offering stable switching performance, high protection level, and reliable operation for industrial automation applications.AutomationComponentInductiveIndustrialIP68longNJ20+U1+W3Pepperl+FuchsProximityRangeSensorSeriesVariKont
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
PEPPERL+FUCHS NJ20+U1+W3 Inductive Sensor
A high-performance inductive sensor from the VariKont series, designed for precise and stable detection in industrial automation environments. Built with a durable PBT housing and featuring a large sensing range, it ensures reliable operation even under harsh conditions. Manufacturer: PEPPERL+FUCHS
Type: Inductive Sensor
Model: NJ20+U1+W3
Part No.: 27820S
Codes: 11688S, 08272S
SN: 10469108656034
Series: VariKont
| Rated Operating Distance (sn) | 20 mm |
| Installation | Not Embeddable |
| Assured Operating Distance (sa) | 0 ... 16.2 mm |
| Reduction Factor rAl | 0.45 |
| Reduction Factor rCu | 0.4 |
| Reduction Factor r304 | 0.8 |
| Operating Voltage | 20 ... 250 V |
| Frequency Range | 45“65 Hz |
| Starting Current | 4 A |
| Operating Current (IL) | 0 ... 500 mA |
| Off-State Current (Ir) | 0 ... 0.5 mA typ. |
| Switching State Indicator | LED, Yellow |
| Standards | EN 60947-5-6:2000, IEC 60947-5-6:1999 |
| Ambient Temperature | -25 ... 70 °C |
| Connection Type | Terminal Compartment |
| Housing Material | PBT |
| Sensing Face | PBT |
| Degree of Protection | IP68 |
| Dimensions | M20 x 118 mm |
