Phcenix Contact 1507803 Termination Resistor
Phoenix Contact Termination Resistor 1507803
The Phoenix Contact Termination Resistor 1507803 offers reliable signal termination for industrial systems with a nominal voltage of 48 V AC / 60 V DC and IP65/IP67 protection.Phoenix Contact Termination Resistor 1507803
The Phoenix Contact Termination Resistor 1507803 is designed for use in industrial electrical systems, offering reliable performance for signal termination. With a nominal voltage of 48 V AC / 60 V DC and a nominal current of 4 A / 25 mA, it is ideal for use in environments where robust connections and high protection standards are required. The resistor is equipped with a straight M12 plug and a free cable end for easy integration into various setups. The high insulation resistance (100 MΩ) and the IP65/IP67 degree of protection ensure durable operation even in harsh environments.
Manufacturer: Phoenix Contact
Type: Termination Resistor
Model: 1507803
Designed for reliable termination in industrial systems, the Phoenix Contact Termination Resistor ensures long-lasting performance even in challenging environments.
| Nominal Voltage (UN) | 48 V AC / 60 V DC |
| Nominal Current (IN) | 4 A / 25 mA |
| Connection 1 | Plug straight M12 |
| Connection 2 | Free cable end |
| Number of Positions | 4 |
| Insulation Resistance | 100 MΩ |
| Degree of Protection | IP65 / IP67 |
| Ambient Temperature | -25 °C ... 90 °C (Plug) |
| Dimensions (H x W x L) | 14.8 x 15 x 56.3 mm |
