Phoenix Contact IB IL 24 DO 2-2A Inline Terminal

Phoenix Contact IB IL 24 DO 2-2A Inline Terminal

The Phoenix Contact IB IL 24 DO 2-2A is a modular inline terminal designed for distributed I/O systems. With 2 output channels, it provides efficient 24 V DC digital signal transmission and is ideal for use in control and automation applications. Featuring spring-cage connections and compact housing, it supports high-speed communication at 500 kbps and ensures reliable operation in demanding environments.

• Manufacturer: Phoenix Contact
• Type: Inline Terminal
• Model: IB IL 24 DO 2-2A
• Part No.: 2726243

Technical Specifications:

• Type: Modular
• No. of Channels: 2
• Supply Voltage: 24 V DC
• Current Draw (Max.): 4 A
• Connection Method: Spring-cage connection
• Nominal Load, Inductive: 48 W
• Transmission Speed: 500 kbps
• Color: Green
• Ambient Temperature (Operation): -25 °C to 55 °C
• Dimensions (H x W x D): 119.8 x 12.2 x 71.5 mm

Applications:

• Distributed control systems
• Industrial automation
• I/O signal processing
