Phoenix Contact Macx MCR-PTB-SP Power Terminal Block
Used
In stock1 unitReady to ship
POWER TERMINAL BLOCK
High-performance Phoenix Contact terminal block for analog systems, with 30 V DC input, max 3.75 A output, integrated fuse, and IP20 protection in a compact housing.3.7530aAnalogBlockContactControldcDINIndustrialIP20MacxMCR-PTB-SPOutputPanelPhoenixPowerrailSignalterminalV
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
PHOENIX CONTACT MACX MCR-PTB-SP POWER TERMINAL BLOCK
Designed for reliable signal and power handling in control panels, the MACX MCR-PTB-SP terminal block from Phoenix Contact offers safe switching, compact dimensions, and industrial-grade protection. Ideal for use in analog signal conditioning systems, it features robust voltage and current specifications, a 5 A fuse, and a wide operating temperature range.
Manufacturer: Phoenix Contact
Type: Power Terminal Block
Model: MACX MCR-PTB-SP
Order No.: 2924184
Product Family: MACX Analog
Maximum Switching Voltage:
50 V AC (2 A)
30 V DC (2 A)
50 V DC (0.22 A)
| Supply Voltage | 19.2 V “ 30 V DC |
| Power Output Current | Max 3.75 A |
| Fuse | 5 A |
| Contact Switching Type | 1 Changeover Contact |
| Stripping Length | 10 mm |
| Temperature Range | -20 to 60 °C |
| Degree of Protection | IP20 |
| Dimensions | 99 x 114.5 x 17.5 mm |
