Phoenix Contact Macx MCR-SL-2NAM-T Isolating Amplifier
New
Available on request
Isolating Amplifier
A slim and efficient isolating amplifier for NAMUR proximity sensors, providing secure signal isolation, stable switching performance, and reliable operation in industrial control and automation systems.AmplifierAutomationCabinetContactControlIndustrialInterfaceIsolatingIsolatorMacxMCR-SL-2NAM-TModuleModulesNamurPhoenixSensorSignal
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Phoenix Contact MACX MCR-SL-2NAM-T Isolating Amplifier
A compact and reliable isolating amplifier designed for safe signal isolation and processing of NAMUR proximity sensors in industrial automation systems. This device ensures accurate signal transmission, electrical isolation, and stable operation in control cabinets and process applications. Manufacturer: Phoenix Contact
Type: Isolating Amplifier
Model: MACX MCR-SL-2NAM-T
MRN: 2865036
No. Of Channels: 2
Input Data
Output Data
Mechanical And Environmental Data
| Nominal Supply Voltage | 24 V DC |
| Supply Voltage Range | 19.2 V DC ... 30 V DC |
| Max. Current Consumption | < 34 mA (24 V DC) |
| Power Dissipation | 1000 mW |
| Power Consumption | 1000 mW |
| Non-Load Voltage | ~ 8 V DC |
| Switching Points (Attenuated) | < 1.2 mA (Blocking) |
| Switching Points (Unattenuated) | > 2.1 mA (Conductive) |
| Available Input Sources | NAMUR Proximity Sensors (EN 60947-5-6) |
| Short-Circuit Current | ~ 8 mA |
| Switching Hysteresis | < 0.2 mA |
| Switching Output | 1 |
| Output Type | Transistor Output, Passive (Per Channel) |
| Minimum Switching Voltage | 3 V DC |
| Maximum Switching Voltage | 30 V DC |
| Width | 12.5 mm |
| Height | 112.5 mm |
| Depth | 114.5 mm |
| Ambient Temperature (Operation) | -20 °C ... 60 °C |
