Phoenix Contact PSR-PS20-1NO-1NC-24DC-SC Coupling Relay
New
Available on request
Coupling Relay
A slim and high-performance coupling relay from the PSRmini family, designed for safety-related and standard control applications, offering fast response times, reliable switching, and compact panel installation.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Phoenix Contact PSR-PS20-1NO-1NC-24DC-SC Coupling Relay
A compact and reliable coupling relay designed for safety-related and standard control applications in industrial automation systems. This relay from Phoenix Contact™s PSRmini family offers fast response times, stable operation, and space-saving installation, making it ideal for control panels and safety circuits. Manufacturer: Phoenix Contact
Type: Coupling Relay
Model: PSR-PS20-1NO-1NC-24DC-SC
Item Number: 2700356
Family: PSRmini
| Overvoltage Category | III |
| Degree of Pollution | 2 |
| Typical Starting Time (Us) | < 100 ms |
| Typical Release Time | < 35 ms |
| Recovery Time | 500 ms |
| Maximum Power Dissipation (Nominal Condition) | 3.28 W |
| Nominal Operating Mode | 100% |
| Rated Insulation Voltage | 250 V AC |
| Rated Control Circuit Supply Voltage (Us) | 20.4 V DC / 26.4 V DC |
| Rated Control Circuit Supply Voltage (Us) | 24 V DC -15% / +10% |
| Rated Control Supply Current (Is) | typ. 45 mA |
| Power Consumption at Us | typ. 1.08 W |
| Inrush Current | typ. 400 mA |
| Safety-Related Output Description | 2 N/O |
| Number of Safety-Related Outputs | 1 |
| Contact Switching Type | 1 |
| Contact Material | AgSnO2 |
| Non-Safety Output Description | PNP |
| Number of Non-Safety Outputs | 1 |
| Width | 6.8 mm |
| Height | 93.1 mm |
| Depth | 102.5 mm |
| Housing Material | PBT |
| Ambient Temperature (Operation) | -40 °C / +70 °C |
| Note | Relay bases and sockets for various relay types are available. For compatible options, please contact us directly or visit our website to view all available models. |
