Phoenix Contact SACC-M12MS-8CON-PG9-M Connector
New
In stock420 unitsReady to ship
M12 Connector
PHOENIX CONTACT SACC-M12MS-8CON-PG9-M 8-position A-coded M12 connector with IP67 protection, Pg9 screw connection, and 30 V AC/DC rating for industrial sensor applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
PHOENIX CONTACT SACC-M12MS-8CON-PG9-M Connector
The PHOENIX CONTACT SACC-M12MS-8CON-PG9-M is a high-quality M12 connector designed for reliable signal transmission in industrial environments. With 8 positions and A-coding, this connector ensures secure and stable connections for universal sensor applications.
Manufacturer: PHOENIX CONTACT
Type: Connector
Model: SACC-M12MS-8CON-PG9-M
Part No.: 15 13 33 4
Code: 220714001
Insulation Characteristics:
Dimensions:
Material Specifications:
Electrical Data:
| Sensor Type | Universal |
| Number Of Positions | 8 |
| Number Of Cable Outlets | 1 |
| Shielded | No |
| Coding | A |
| Pg Screw Connection | Pg9 |
| Overvoltage Category | II |
| Degree Of Pollution | 3 |
| Width | 20 mm |
| Height | 20 mm |
| Length | 60 mm |
| Wrench Size, Union Nut | 16 mm |
| Wrench Size, Counter Nut | 17 mm |
| External Dimensions (Outside Diameter) | 6 mm ... 8 mm |
| Housing Diameter | 20 mm |
| Flammability Rating (UL 94) | HB |
| Seal Material | Silicon |
| Material Of Grip Body | PBT |
| Contact Material | CuZn |
| Contact Surface Material | Au |
| Contact Carrier Material | PA |
| Material For Screw Connection | Brass, Nickel-Plated |
| Nominal Voltage (UN) | 30 V AC/DC |
| Nominal Current (IN) | 2 A |
| Degree Of Protection | IP67 |
| Ambient Temperature (Operation) | -40 °C ... 85 °C |
