Pilz Pnoz S5 C 24VDC 2N/O 2N/OT 751105 Time Monitoring Relay

Name: PILZ PNOZ S5 C 24VDC 2N/O 2N/OT 751105 TIME MONITORING RELAY
SKU: 1083032
Availability: LimitedAvailability

pilz-pnoz-s5c24vdc2n-o2n-ot751105-time-monitoring(used)

pilz-pnoz-s5c24vdc2n-o2n-ot751105-time-monitoring(used)-1

pilz-pnoz-s5c24vdc2n-o2n-ot751105-time-monitoring(used)-2

Used

In stock1 unitReady to ship

Time Monitoring Relay

The Pilz PNOZ S5 C 24VDC 2N/O 2N/OT time monitoring relay provides precise time control and reliable safety performance with 24 V DC operation and compact IP40 design.

Manufacturer

PILZ

SKU

1083032

Category

Safety Relays

Condition

Used

24v 24VDC 4NO Automation C Controller dc Industrial IP40 Module monitoring Output Pilz Pnoz Relay S5 Safety Time Timing

Massive Inventory

Global Shipping

Expert Support

Quality Guaranteed

Pilz PNOZ S5 C 24VDC 2N/O 2N/OT Time Monitoring Relay

The Pilz PNOZ S5 C 24VDC 2N/O 2N/OT Time Monitoring Relay is a high-performance safety relay designed for reliable time monitoring and control in industrial safety systems. It provides dependable switching, compact design, and durable construction for precise safety operations.

Manufacturer: Pilz

Type: Time Monitoring Relay

Model: PNOZ S5 C 24VDC 2N/O 2N/OT

Part No.: 751105

Supply Voltage	24 V DC
Power Consumption	4 W
Inputs No.	2
Relay Output Contacts	4 Normally Open (NO)
Voltage AC1 Safety Contact	240 V
Max. Current AC1 Safety Contact	6 A
Voltage AC15 Safety Contact	230 V
Max. Current AC15 Safety Contact	3 A
Voltage DC13 Safety Contact	24 V
Protection Class	IP40
Connection Terminal	Screw Terminal Plug-In
Ambient Temperature	-10 / 55 °C
Dimensions	100 x 22.5 x 120 mm
