Pilz Pnoz S7.1C 24VDC 3N/O Cascade Contact Expansion Module
Used
In stock4 unitsReady to ship
Contact Expansion Module
The PILZ PNOZ S7.1C (751167) offers 3 N/O outputs and 24V DC operation in a compact plug-in terminal design, ideal for extending safety relay systems.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
PILZ PNOZ S7.1C 24VDC 3N/O CASCADE Contact Expansion Module
The PILZ PNOZ S7.1C (Part No. 751167) is a high-performance contact expansion module designed for safety relay systems. It features 3 normally open (N/O) outputs and a compact spring-loaded, plug-in terminal design, making it an ideal choice for space-saving and secure safety automation.
Manufacturer: PILZ
Type: Contact Expansion Module
Model: PNOZ S7.1C 24VDC 3N/O CASCADE
Part No.: 751167
| Supply Voltage | 24V DC |
| Voltage AC1 Safety Cont. | 240 V |
| Max. Current AC1 Safety Cont. | 6 A |
| Voltage DC1 Safety Cont. | 24 V |
| Max. Current DC1 Safety Cont. | 6 A |
| Power Consumption | 2W |
| Outputs | 3 N/O |
| Connection Terminal | Spring-loaded terminal |
| Terminal Style | Plug-in |
| Ambient Temperature | -10 “ 55 °C |
| Dimensions (H x W x D) | 100 x 17.5 x 120 mm |
