PMI MSB20TSSSFCN Linear Guideway Carriage

In stock12 unitsReady to ship

LINEAR GUIDEWAY CARRIAGE

PMI MSB20TSSSFCN linear guideway carriage, square type with light preload, accuracy grade N, and dust protection SS. Compact and reliable solution for precision linear motion.

Manufacturer
PMI
SKU
1086790
Condition
New
Share
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed

PMI MSB20TSSSFCN LINEAR GUIDEWAY CARRIAGE

The PMI MSB20TSSSFCN is a precision linear guideway carriage designed for smooth and accurate motion in industrial applications. With a compact square type carriage, light preload, and reliable dust protection, it ensures stability and long service life.

Manufacturer: PMI

Type: Linear Guideway Carriage

Model: MSB20TSSSFCN

Code: WL-4943515-371

Size20
Height of System28 mm
Height of Block22 mm
Width42 mm
Length48 mm
B32 mm
Dynamic Load Rating9700 N
Static Load Rating14200 N
PreloadFC (Light preload)
Accuracy GradeN
Carriage TypeTS (Square type)
Dust Protection Option of CarriageSS
NoteWe also provide the corresponding rails (guideways) in a wide range of lengths - please ask us if you need rails to match your bearing
