Rexnord 64B-1 Simplex Roller Chain

Manufacturer: REXNORD
Type: Simplex Roller Chain
Model: 64B-1

DIN/ISO 606
Chain no. 64B-1
PitchP: 101.6 mm
Roller diameter d1: 63.5 mm
Width between inner plates b1: 60.96 mm
Pin diameter d2 max/L max: 39.40/130.0 mm
Pin length Lc max: 138.5 mm
Plate thickness T: 15.00/13.0mm
Ultimate tensile strength Q min: 1120.0/254544 kN/lbf
Average tensile strength Q0: 1240 kN
Weight per meter q: 46 kg/m
