Rosemount 396P-01-10-55 PH Sensor
Used
In stock1 unitReady to ship
PH Sensor
Rosemount 396P PT100 industrial PH sensor with GPLR glass electrode, PT100 temperature element, 0“14 PH measuring range, and preamplifier output.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Rosemount 396P PT100 PH Sensor
The Rosemount 396P PT100 PH sensor is designed for reliable pH and ORP measurement in industrial process applications. This sensor features GPLR glass electrode technology and integrated PT100 temperature element for accurate monitoring in demanding environments.
Manufacturer: Rosemount
Type: PH Sensor
Model: 396P PT100
Part No.: 396P-01-10-55
Rev.: K
Measured Range:
Materials:
| Measuring Electrode | PH - General Purpose Low Resistivity (GPLR) Glass |
| For Use With | Rosemount 56, 1056, 1057, 1066, And 5081 |
| PH | 0 ... 14 |
| ORP | -1500 / 1500 mV |
| Temperature Element | PT100 |
| Temperature Range | 0 / 100 °C |
| Pressure Range - Hemi Bulb | 0 / 100 psig |
| Sensor Output | Preamplifier |
| Length, Diameter | 168.28, 25 mm |
| Sensor Body | Tefzel® |
| PH Electrode | Glass |
| Connection | 25 ft (7.62 m) Cable |
