Samson 6102-3401.00 Electropneumatic I/P Converter
New
Available on request
Electropneumatic I/P Converter
The SAMSON 6102-3401.00 electropneumatic I/P converter transforms a 4“20 mA signal into a precise pneumatic output, ensuring reliable control in automation and process applications.0.2-14-20mA61026102-3401.00881410barControlConverterElectropneumaticI/PIndustrialOutputPneumaticSamsonSeriesSignal
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
SAMSON 6102-3401.00 Electropneumatic I/P Converter
The SAMSON 6102340100 Electropneumatic I/P Converter is a precision-engineered device designed to convert standardized electrical current signals into proportional pneumatic control signals. It provides stable and accurate operation, making it ideal for use as an interface between electric controllers and pneumatic control valves.
Manufacturer: SAMSON
Type: Electropneumatic I/P Converter
Model: 6102-3401.00
Ref. No.: 881410
Series: 6102
| Application | Instruments for conversion of a standardized direct current signal into a pneumatic control signal, applicable as intermediate elements between electric controllers and pneumatic control valves |
| Supply Air Pressure | 0.4 bar |
| Input Signal Current | 4 ... 20 mA |
| Output Pneumatic Pressure | 0.2 / 1 bar |
| Protection Class | IP54/IP50 |
| Ambient Temperature | -20 / 80 °C |
| Dimensions | 183 x 53 x 65 mm |
