Schneider Electric BMH1001P16A2A Servo Motor

Manufacturer: ELAU – SCHNEIDER ELECTRIC

Type: SERVO MOTOR

Model: BMH1001P16A2A

Rated Voltage : 480 Vrms

Max. Current: 11.9 Arms

Stall Current: 3.15 Arms

Normal Speed: 4000 Revolution Per Minute (rpm)

Max. Speed: 6000 Revolution Per Minute (rpm)

Nominal Torque: 3.1 Nm

Holding Brake: With Brake

Nominal Power: 1300 W

Flange Size: 100 mm

Motor Length: 128.6 mm

Shaft Diameter: 19 mm

Shaft Length: 40 mm

Protection Class: IP50(65)

Weight: 3.70 kg
