SCHNEIDER ELECTRIC ATV32HU22N4 Variable Speed Drive
The SCHNEIDER ELECTRIC ATV32HU22N4 variable speed drive from the Altivar 32 range is designed for precise motor control in industrial automation applications. It provides flexible input and output control, wide frequency range, and reliable performance for three-phase motor systems.
Manufacturer: SCHNEIDER ELECTRIC
Type: Variable Speed Drive
Model: ATV32HU22N4
Range: Altivar 32
Component Name: ATV32
| Input Supply Voltage | 3-Phase 380 / 500 V AC |
| Input Rated Current | 8.7 A |
| Input Frequency | 50 / 60 Hz |
| Output Rated Voltage | 3-Phase 0 / 500 V AC |
| Output Rated Current | 5.5 A |
| Output Frequency | 0 / 599 Hz |
| Motor Power | 3 kW / 4 HP |
| Discrete Inputs | 7 |
| Discrete Outputs | 3 |
| Analogue Inputs | 3 |
| Analogue Outputs | 1 |
| Protection Class | IP20 |
| Ambient Temperature | -10 / 50 °C |
| Dimensions | 325 x 60 x 245 mm |
