Schneider RXM3AB2BD Miniature Plug IN Relay

Manufacturer: Schneider

Type: Miniature Plug in Relay

Model: RXM3AB2BD

Part No: 940363

Control circuit voltage Uc: 24 V DC

Rated operational current Ie: 10 A at 250 V (AC) NO conforming to IEC, 10 A at 277 V (AC) conforming to UL, 10 A at 30 V (DC) conforming to UL

Power in HP: 1/3 HP 120 VAC, 1 HP 250 VAC

Contacts type and composition: 3 Changeover contacts (Single pole double through)

Contacts material: AgNi

Operating Temperature: -40 … +55 °C

Degree of protection: IP40

Dimensions: 27 x 21 x 53.7 mm
