Sick RLY3-OSSD200 Safety Relay

Manufacturer: SICK
Type: Safety Relay
Model: RLY3OSSD200
Part No: 1085344

Supply Voltage: 24 V DC
Power Consumption: 2.5 W
Inputs No.:
2 Safety Inputs
1 Input for Reset Pushbutton or External Device Monitoring (EDM)
Outputs No.:
2 Enabling Current Paths (Safe)
2 Application Diagnostic Outputs (Not Safe)
1 Test Pulse Output (Not Safe)
Contact: PNP/Push-Pull/2 Normally Open (NO)
Contact Ratings: 10 … 230 V AC/DC, 12 A
Protection Class: IP20
Ambient Temperature: -25 … 55 °C
Dimension: 124.6 x 18 x 85.5 mm
