Sick VS/VE18-4P3140 Through-Beam Photoelectric Sensor

Manufacturer: SICK

Type: THROUGH-BEAM PHOTOELECTRIC SENSOR

Set Model: VS/VE18-4P3140

Set Part No.: 6013677

Sensing Range: 0 … 14 m

Response time max.: 2 ms

Operating Voltage: 10 … 30 V DC

Ripple: 10%

Switching frequency: 250 Hz

Output current: 100 mA DC

Switching output: PNP

Switching mode: Light/dark switching

Type of light: Infrared light

Light spot size (distance): 700 mm, 14 m

Angle of dispersion: 2.8°

Connector type: Male connector, 4-pin

Protection class: III

Enclosure rating: IP67

Ambient Operating temperature: -25 … 70°C

Diameter, housing length: 18, 78 mm

Housing: Threaded type

Housing material: Nickel-plated Brass

Weight: 240 g

Mounting: Nickel-plated Brass

Condition: New
