Sick WSU26/3-103A00 Photoelectric Sensor

Manufacturer: Sick

Type: Photoelectric Sensor

Model: WSU26/3-103A00

Order No: 1 047 984

Supply Voltage: 24 V DC (19.2 V DC … 28.8 V DC)

Power Consumption: 8 W / 6 W

Type of Light: Infrared Light

Scanning Range: 70 m

Detection Capability: 30 mm

Response Time: ≤ 22 ms

Synchronization: Optical

Connection Type: PG gland (13,5)

Design: Rectangular

Wave length: 950 nm

Ambient Temperature: -25…55 °C

Protection Class: IP67

Number of Beams: 1

Dimension of the Light Path: 15…70 m

Material: Aluminum

Dimensions: 156 x 116 x 50 mm
