Siemens 1FL6066-1AC61-2LB1 Servo Motor
New
In stock1 unitReady to ship
Servo Motor Industrial SIEMENS servo motor with 3000 rpm rated speed, integrated encoder, and protection for high-precision motion control and automation applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| MNR | 1FL6066-1AC61-2LB1 |
| SN | LMH/M922912043001 |
| FS | 02 |
| Family | SIMOTICS S-1FL6 |
| Ref No | A5E41078271 |
| Rated voltage | 203 v |
| Rated power | 1.75 kW |
| Rated speed | 2,000 rpm |
| Rated torque (100 K) | 8.36 Nm |
| Rated current | 5.3 A |
| Max. speed | 3,000 rpm |
| Maximum torque | 25.10Nm |
| Max. current | 15.9 A |
| Static torque | 11 Nm |
| Static current | 6.6 A |
| Torque constant | 1.500 Nm/A |
| Thermal class | B (130 °C) |
| Operation | 0 … 40 °C |
| Shaft height | 65 |
| Encoder system | Absolute encoder 20 bit + 12 bit multiturn Cooling: Natural cooling |
| Shaft end | Feather key |
| Radial runout tolerance | Class N |
| Vibration severity grade | Grade A |
| Degree of protection | IP65 |
| Design acc. to Code I | IM B5 (IM V1, IM V3) |
| Connection type | Angular connector (rotatable) |
| Attached encoder | ABS.MT.20-bit |
| Holding torque | M4Br 12.00 Nm |
| Rated voltage, brake | 24 V DC 10 % |
| Opening time | 180 ms |
| Closing time | 60 ms |
| Connection | Circular connector |
| Stock key | CON-003 |
| Condition | New |
| SKU | 1100401 |
| Weight | 15,38 |
