Siemens 1FT5066-0AF01-2-Z Permanent Magnet Motor

SIEMENS 1FT5066-0AF01-2-Z PERMANENT MAGNET MOTOR

Designed for high-efficiency industrial automation systems, the Siemens 1FT5066-0AF01-2-Z Permanent Magnet Motor delivers reliable performance with precise control. Equipped with an EBD brake, incremental encoder, and tachometer, this motor ensures superior operational accuracy and safety across a range of applications.

Manufacturer: SIEMENS
Type: Permanent Magnet Motor
Model: 1FT5066-0AF01-2-Z
NR E: 8K10 8072 36 006

Technical Specifications

• Supply Voltage: 150 V
• Stall Torque: 6.5/8.0 Nm
• Rated Torque: 5.6 Nm
• Stall Current: 16.3/20 A
• Rated Speed: 3000 rpm
• Protection Class: IP64
• Thermal Class: F
• Duty: S1

Brake Information

• Brake Type: EBD 0.8 M
• Brake Voltage: 24 V
• Brake Power: 18 W

Tachometer

• Model: 1FU1050-6HF
• Constant Voltage Ke: 13.3 mVmin

Encoder (Incremental)

• Model: SIEMENS 6FX2001-2CC50
• Resolution: 2500 Pulses per Revolution (PPR)
• Shaft Diameter: 6 mm
• Shaft Length: 10 mm
• Voltage Supply: 5 VDC
• Max Current: 100 mA
• Output Circuits: TTL (RS 422)
• Max Rotation Speed: 7200 rpm
• Sampling Frequency: 0 / 160 kHz
• Output Connections: Flexible cable
• Protection Class: IP64
• Temperature Range: -40 to 100 °C
