Siemens 3RH1122-1AP00 Contactor Relay

Manufacturer: SIEMENS
Type: Contactor Relay
Series: SIRIUS
Model: 3RH1122-1AP00
Successor: 3RH2122-1AP00

Supply Voltage: 230 V AC,50 … 60 Hz
Rated insulation voltage Ui: 690 V AC
Short-circuit protection of the auxiliary switch required: Fuse 10 A
Rated operational current AC-15 @ 400 V: 3 A
Rated operational current AC-3 @ 400 V: 1.1 A
No. of Contacts: 2 NO + 2 NC
Enclosure Rating: IP20
Dimensions: 57.5 x 45 x 72 mm
Ambient temperature: -20 … 60°C
Size: S00
