Siemens 3RH2911-1HA12 Auxiliary Switch Block
Manufacturer: Siemens
Type: AUXILIARY SWITCH BLOCK
Part No.: 3RH2911-1HA12
Brand Name: SIRIUS
Insulation Voltage: 690 V
surge voltage resistance rated value: 6 kV
Rated Operational Voltage: 24 … 230 V
Rated Operational Current Max.: 0.3 … 10 A
Frequency: 50 … 60 Hz
No of Contact: 1 Normally Open (NO) + 2 Normally Closed (NC)
Auxiliary Contact Ratings: 240 V AC, 10 A
Type of Electrical Connection: Screw-Type Terminals
Protection Class: IP20
Temperature: -25 … 60 °C
Dimensions: 37.5 x 36 x 43.7 mm
