SIEMENS 3TK2822-1CB30 Safety Relay The SIEMENS 3TK2822-1CB30 Safety Relay features 2 normally open contacts, 24V DC supply, and a finger-safe design, offering reliable protection and safety for industrial systems.
SIEMENS 3TK2822-1CB30 Safety Relays
The SIEMENS 3TK2822-1CB30 Safety Relay is a high-performance relay designed for ensuring safety and reliable operation in industrial environments. With features such as finger-safe protection, screw and snap-on mounting, and a high thermal current rating, it offers optimal protection for machinery and personnel in control systems.
- Manufacturer: Siemens
- Type: Safety Relays
- Model: 3TK2822-1CB30
Technical Specifications:
- Supply Voltage: 24 V DC
- Insulation Voltage Rated Value: 300 V
- Thermal Current: 5 A
- Mounting Type: Screw and snap-on mounting
- Type of Electrical Connection: Screw-type terminals
- DC Resistance of the Cable Maximum: 30 „¦
- Cable Length: 500 m
- Protection Against Electrical Shock: Finger-safe
- Contact Configuration: 2 Normally open (NO)
- Torque: 0.8 / 1.2 Nm
- Frequency: 50/60 Hz
- Protection Class: IP40, IP20
- Ambient Temperature: -25 / 60 °C
- Dimensions: 120 x 22.5 x 120 mm
The SIEMENS 3TK2822-1CB30 Safety Relay provides high reliability in industrial safety applications. Its flexible installation options and robust design, including finger-safe protection and a high thermal current rating, make it ideal for protecting electrical systems and ensuring safe operation across a wide temperature range.
