Siemens 5SU1356-7KK06 Residual Current Circuit Breaker

Name: SIEMENS 5SU1356-7KK06 RESIDUAL CURRENT CIRCUIT BREAKER
SKU: 1084776
Availability: LimitedAvailability

siemens-3se5232-0bc05-position-switch(new)

New

Available on request

RCBO

A compact and reliable Siemens SENTRON residual current circuit breaker providing combined protection against residual currents, overloads, and short circuits in low-voltage electrical installations.

Manufacturer

SIEMENS

SKU

1084776

Category

Circuit Breakers

Condition

New

356-7KK06 5SU1 Breaker Circuit Components Current Device Distribution Electrical Industrial low Protection Rcbo Residual Sentron Siemens voltage

Massive Inventory

Global Shipping

Expert Support

Quality Guaranteed

Siemens SENTRON 5SU1 356-7KK06 RCBO

A high-performance residual current circuit breaker with overcurrent protection, designed to provide reliable protection against short circuits, overloads, and residual currents in low-voltage electrical installations. This SENTRON RCBO ensures fast tripping response and dependable operation in residential, commercial, and industrial distribution systems. Manufacturer: Siemens

Product Brand Name: SENTRON

Product Designation: RCBO

Type: Residual Current Circuit Breaker RCBO

MRN: 5SU1 356-7KK06

Code: C6

Design Of The Product	Instantaneous
Number Of Poles	2
Number Of Poles With Protection	1
Design Of Pole	1P+N
Tripping Characteristic	Class C
Type Of Voltage	AC
Rated Insulation Voltage (Ui)	264 V
Rated Surge Voltage Resistance	4,000 V
Surge Current Resistance (8/20 µs)	1 kA
Rated Tripping Fault Current	30 mA
Rated Supply Voltage (AC)	230/240 V
Minimum Voltage For Testing Equipment	195 V
Operating Frequency	50 Hz
Rated Supply Voltage Frequency	50 Hz
Protection Class	IP20
Maximum Power Loss	1.9 W
Height	90 mm
Width	36 mm
Depth	77 mm
Installation Depth	70 mm
Number Of Modular Width Units	2
Ambient Temperature (Operation)	-25 °C to +55 °C
