Siemens 6EC1 310-3A Potted Block 1 UP Counter
New
In stock1 unitReady to ship
POTTED BLOCK 1 UP COUNTER
Siemens SIMATIC C1 Up Counter (MRN: 6EC1 310-3A) is a compact and efficient single-direction counter block with synchronous counting at 80 Hz and decimal decoded outputs.310-3A6EC180BlockC1counterCountingDecimalDirectionHzIndustrialModuleOutputPottedQuantitySiemensSimaticSingleSynchronousup
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
SIEMENS SIMATIC C1 POTTED BLOCK 1 UP COUNTER
The Siemens SIMATIC C1 Potted Block 1 Up Counter (MRN: 6EC1 310-3A) is designed for reliable performance in single-direction counting applications such as quantity tracking and piece counting. This block features a counting decade and inputs for counts, directional pulses, and reset.
Thanks to its synchronous counting principle, it supports a consistent maximum counting frequency of 80 Hz regardless of the number of decades. With decimal decoded outputs, it allows for straightforward querying of the current count.
Manufacturer: SIEMENS
Family: SIMATIC C1
Type: Potted Block 1 Up Counter
MRN: 6EC1 310-3A
| Application | Arbitrary counting tasks (single direction), quantity and piece counting |
| Inputs | Counts, directional pulses, reset |
| Output | Decimal decoded |
| Counting Frequency | Max. 80 Hz (synchronous counting) |
| Current | 50 mA |
