Siemens 6ES7 531-7NF10-0AB0 Analog Input Module
New
Available on request
Analog Input Module
A high-speed Siemens analog input module with eight channels for voltage and current measurement, designed for SIMATIC S7-1500 PLC systems and advanced industrial automation applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Siemens SIMATIC S7-1500 Analog Input Module
A high-speed analog input module designed for precise voltage and current signal acquisition in advanced industrial automation systems. This module is part of the SIMATIC S7-1500 family and is engineered for seamless integration into Siemens PLC environments using TIA Portal and STEP 7 engineering platforms. Manufacturer: Siemens
Type: Analog Input Module
Family: SIMATIC S7-1500
MRN: 6ES7531-7NF10-0AB0
Product Type Designation: AI 8xU/I HS HW
Functional Status: From FS01
Firmware Version: V2.1.0
| Engineering Software | STEP 7 TIA Portal configurable/integrated from V14 |
| STEP 7 Compatibility | Configurable/integrated from V5.5 SP3 |
| PROFIBUS | GSD version/GSD revision V1.0 / V5.1 |
| PROFINET | GSD version/GSD revision V2.3 |
| Supply Voltage (DC) | 24 V |
| Permissible Voltage Range (DC) | 19.2 V “ 28.8 V |
| Current Consumption (Max.) | 240 mA |
| Power From Backplane Bus | 1.15 W |
| Power Loss (Typical) | 3.4 W |
| Number Of Analog Inputs | 8 |
| Current Measurement Inputs | 8 |
| Voltage Measurement Inputs | 8 |
| Width | 35 mm |
| Height | 147 mm |
| Depth | 129 mm |
| Ambient Temperature (Horizontal Installation, Min.) | ˆ’25 °C (from FS02) |
| Ambient Temperature (Horizontal Installation, Max.) | 60 °C |
