Siemens 6ES7277-0AA22-0XA0 Profibus DP Slave Module
PROFIBUS DP Slave Module
The Siemens SIMATIC S7-2000 PROFIBUS DP Slave Module offers 24 V DC supply, supports PROFIBUS DP and MPI protocols, with RS 485 interface and max. 90 mA output at 5 V DC, ideal for industrial automation systems.Siemens SIMATIC S7-2000 PROFIBUS DP Slave Module
The Siemens SIMATIC S7-2000 PROFIBUS DP Slave Module offers efficient and reliable communication for industrial automation systems. With support for both PROFIBUS DP and MPI protocols, it enables seamless integration into your Siemens automation network. This module is designed for optimal performance with low power loss and a compact design, making it ideal for industrial applications.
Manufacturer: Siemens
Type: PROFIBUS DP Slave Module
Model: S C-XNX18514 / EM 277
Family: SIMATIC S7-2000
The Siemens SIMATIC S7-2000 PROFIBUS DP Slave Module ensures high-speed data transfer and low power consumption, making it an ideal choice for control and monitoring in industrial automation systems.
| Supply Voltage | 24 V DC (21 to 28 V DC) |
| Input Current from Backplane Bus 5 V DC | Max. 150 mA |
| Output Voltage | 5 V DC, 24 V DC |
| Output Current | Max. 90 mA at 5 V DC, 120 mA at 24 V DC |
| Power Loss | Typ. 2.5 W |
| Interfaces | RS 485 |
| Bus Protocol | PROFIBUS DP (slave), MPI (slave) |
| Transmission Rate | 9.6 KB to 12 MB |
| Dimensions | 71.2 x 80 x 62 mm |
