Siemens 6GK1901-0DB20-6AA0 Connector
Siemens 6GK19010DB206AA0 SIMATIC NET IE FC M12 Plug PRO “ PROFINET Reliable industrial Ethernet connector with **M12 D-coded plug**, **10/100 Mbit/s transfer rate**, **rugged metal enclosure**, and **IP65/IP67 protection**, ideal for **PROFINET networking**.
Siemens 6GK19010DB206AA0 SIMATIC NET IE FC M12 Plug PRO “ PROFINET, IP65/IP67
The Siemens 6GK19010DB206AA0 SIMATIC NET **IE FC M12 Plug PRO** is a **high-performance industrial Ethernet connector**, designed for **PROFINET networks and reliable industrial communication**. With a **rugged metal enclosure, IP65/IP67 protection, and FastConnect technology**, this connector ensures **secure and efficient network connections in harsh environments**.
Key Product Details:
Manufacturer: Siemens
Type: IE FC M12 Plug PRO (PROFINET) / Accessory Cabling Kit
MNR: 6GK19010DB206AA0
Family: SIMATIC NET
Suitability for Use: For connecting electrical cables to SCALANCE X208PRO, ET200 PRO PN, or ET200 eco PN using FastConnect system
Transfer Rate:
Type of Electrical Connection:
Number of Electrical Connections:
Designed for **industrial automation and networking**, the Siemens 6GK19010DB206AA0 IE FC M12 Plug PRO provides **ruggedized Ethernet connectivity, superior durability, and seamless integration into PROFINET communication systems**.
| Industrial Ethernet | 10 Mbit/s |
| Industrial Ethernet | 100 Mbit/s |
| For Industrial Ethernet FC TP Cables | Integrated cut-and-clamp contacts for 4-wire TP FC installation cable AWG22 |
| For Network Components or Terminal Equipment | M12 Connector (D-coded) |
| For Industrial Ethernet FC TP Cables | 4 |
| For Network Components or Terminal Equipment | 1 |
| Material of the Enclosure | Metal |
| Ambient Temperature During Operation | -40 to +85°C |
| Protection Class | IP65/IP67 |
| Dimensions | 19 x 19 x 73 mm |
