Siemens 6SE6430-2AD31-8DA0 Frequency Inverters

SIEMENS MICROMASTER 430 FREQUENCY INVERTER

The Siemens Micromaster 430 (Model: 6SE6430-2AD31-8DA0) is a robust and versatile frequency inverter designed for industrial motor control applications. With advanced features, high performance, and integrated operator panel, it ensures precise speed regulation and energy efficiency for various automation systems.

Manufacturer: SIEMENS
Type: Frequency Inverter
Model: 6SE6430-2AD31-8DA0
Family: Micromaster 430
Serial No.: T-U12762000005
Contain of: SIEMENS 6SE6400-0BE00-0AA0 BASIC OPERATOR PANEL

Input Specifications

• Voltage Rating: 380 / 480 V AC
• Rated Current: 37 A
• Frequency: 47 / 63 Hz
• Number of Phases: 3 AC

Output Specifications

• Voltage Rating: 480 V
• Rated Current: 38 A
• Number of Phases: 3 AC
• Pulse Frequency: 4000 Hz
• Output Frequency for V/F Control: 0 / 650 Hz
• Rated Power: 18.5 kW / 25 hp

General Specifications

• Operating Temperature: 10 / 50 °C
• Dimensions (W x H x D): 275 x 520 x 245 mm
• Protection Class: IP20
