SKF 24034 CC/W33 Spherical Roller Bearing
New
In stock1 unitReady to ship
Spherical Roller Bearing
The SKF 24034 CC/W33 is a heavy-duty spherical roller bearing with a 170 mm bore, sheet metal cage, and W33 design for enhanced lubrication. It supports up to 963 kN dynamic load and runs at speeds up to 2400 rpm.170mm24034bearingbearingsboreCageCapacityCC/W33DesignHighIndustrialLoadMetalMisalignmentRollersheetSKFSphericalW33
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
SKF 24034 CC/W33 Spherical Roller Bearing
The SKF 24034 CC/W33 is a high-capacity spherical roller bearing engineered for applications requiring durability, heavy load support, and misalignment tolerance. Featuring a W33 design with an annular groove and three lubrication holes, and a sheet metal cage, this bearing is built for superior lubrication and high-performance under demanding conditions.
Manufacturer: SKF
Type: Spherical Roller Bearing
Model: 24034 CC/W33
| Bore Diameter (d) | 170 mm |
| Outer Diameter (D) | 260 mm |
| Width (B) | 90 mm |
| Dynamic Load Rating (Cr) | 963 kN |
| Static Load Rating (C0r) | 1460 kN |
| Fatigue Load Limit | 137 kN |
| Reference Speed | 1600 rpm |
| Limiting Speed | 2400 rpm |
| Cage Type | Sheet Metal |
| Design | W33 - Annular groove and three lubrication holes in the outer ring |
