SKF 24136 CC/W33 Spherical Roller Bearing
Used
In stock1 unitReady to ship
SPHERICAL ROLLER BEARING
SKF 24136 CC/W33 Spherical Roller Bearing with 180 mm bore, 300 mm outer diameter, and 118 mm width. High load capacity, 1100 rpm reference speed, and W33 lubrication design.18024136300bearingboreCapacityCC/W33CylindricaldiameterDutyHeavyHighLoadlubricationmmOuterRollerSKFSphericalW33
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
SKF 24136 CC/W33 SPHERICAL ROLLER BEARING
The SKF 24136 CC/W33 is a robust spherical roller bearing engineered for heavy-duty applications. With its high load capacity, sheet metal cage, and advanced lubrication design, this bearing provides reliable operation and extended service life in demanding environments.
Manufacturer: SKF
Type: Spherical Roller Bearing
Model: 24136 CC/W33
| Bore Diameter (d) | 180 mm |
| Outer Diameter (D) | 300 mm |
| Width (B) | 118 mm |
| Basic Load Ratings, Radial | Dynamic Cr: 1449 kN / Static C0r: 2160 kN |
| Reference Speed | 1100 rpm |
| Limiting Speed | 1600 rpm |
| Cage Material | Sheet Metal |
| Bore Type | Cylindrical |
| Lubrication | W33 “ three lubrication holes (equally spaced) and lubrication groove on the outer ring |
