SKF 3206 A-2RS1TN9/C3MT33 Double ROW Angular Contact Ball Bearing
New
In stock5 unitsReady to ship
Double Row Angular Contact Ball Bearing
SKF 3206 A-2RS1TN9/C3MT33 Double Row Angular Contact Ball Bearing offers a 30 mm bore and 62 mm outer diameter with a dynamic load capacity of 30,500 N. Ideal for high-speed applications with medium temperature resistance and dual sealing.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
SKF 3206 A-2RS1TN9/C3MT33 Double Row Angular Contact Ball Bearing
The SKF 3206 A-2RS1TN9/C3MT33 Double Row Angular Contact Ball Bearing is designed for high load capacity and precise angular contact. It is ideal for high-speed and demanding applications with its durable construction and optimal sealing features.
Manufacturer: SKF
Type: Double Row Angular Contact Ball Bearing
Model: 3206 A-2RS1TN9/C3MT33
| Bore Diameter (d) | 30 mm |
| Outer Diameter (D) | 62 mm |
| Width (B) | 23.8 mm |
| Contact Angle | 30 ° |
| Dynamic Load Rating (Cr) | 30,500 N |
| Static Load Rating (C0r) | 22,000 N |
| Limiting Speed | 7,500 rpm |
| Cage | TN9, Nylon Glass Fibre Filled |
| Sealing | 2RS1, Seal on Both Sides |
| Clearance | C3 |
| Temperature | MT33, Medium Temperature Ranges |
