SKF 3208 A-2RS1TN9/C3MT33 Double ROW Angular Contact Ball Bearing
New
In stock1 unitReady to ship
Double Row Angular Contact Ball Bearing
The SKF 3208 A-2RS1TN9/C3MT33 features a 40mm bore, 80mm outer diameter, 30° contact angle, TN9 cage, C3 clearance, and 2RS1 seals for high-performance applications.2RS1320840mm80mmA-2RS1TN9/C3MT33AngularBallbearingboreC3CageClearanceContactdiameterDoublehigh-performanceOuterRowSealedSKFTN9
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
SKF 3208 A-2RS1TN9/C3MT33 Double Row Angular Contact Ball Bearing
The SKF 3208 A-2RS1TN9/C3MT33 is a high-performance double row angular contact ball bearing designed for applications requiring high radial and axial load capacity. Featuring a contact seal on both sides, a reinforced polyamide cage, and C3 clearance, this bearing ensures durability and efficient operation in demanding conditions.
Manufacturer: SKF
Type: Double Row Angular Contact Ball Bearing
Model: 3208 A-2RS1TN9/C3MT33
Basic Load Ratings, Radial:
| Bore Diameter (d) | 40 mm |
| Outer Diameter (D) | 80 mm |
| Width (B) | 30.2 mm |
| Contact Angle | 30° |
| Dynamic (Cr) | 48 kN |
| Static (C0r) | 36.5 kN |
| Limiting Speed | 5600 r/min |
| Seal | 2RS1, Contact Seal on Both Sides |
| Cage | TN9, Glass Fibre Reinforced PA66 Cage |
| Grease Suffix | MT33 |
| Clearance Class | C3 |
