SMW 150/67VNK Rotating Hydraulic Cylinder
Used
In stock1 unitReady to ship
SMW Rotating Hydraulic Cylinder 150/67VNK
Hydraulic cylinder with 45 bar pressure, 68 kN draw pull, and 5500 rpm max speed, designed for horizontal installation with safety valves.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
SMW Rotating Hydraulic Cylinder 150/67VNK
The SMW 150/67VNK Rotating Hydraulic Cylinder is designed with a short and compact profile, offering low mass and power consumption. This cylinder is intended for horizontal installation and features safety valves along with an excess pressure relief valve for enhanced reliability. It is designed to operate with oil HM32 ISO 3448.
- Manufacturer: SMW
- Type: Rotating Hydraulic Cylinder
- Model: 150/67VNK
- Features: Short design, low mass, low power consumption, horizontal installation, safety valves, and excess pressure relief valve
- Piston Area: 152 cm²
- Through-Hole: 67.5 mm
- Max. Pressure: 45 bar
- Draw Pull at 45 bar: 68 kN
- Max. Speed: 5500 rpm
- Power Absorption: 1.5 kW
- Moment of Inertia J: 0.07 kg·m²
