SNR 6228 C3F25 Deep Groove Ball Bearing
New
In stock1 unitReady to ship
DEEP GROOVE BALL BEARING
SNR 6228 C3F25 bearing with 140 mm bore, 250 mm outer diameter, 42 mm width, and C3 clearance. Supports 184 kN dynamic load and 150 kN static load with high-speed performance.1402506228BallbearingboreC3C3F25ClearanceDeepdiameterDutyGrooveHeavyHighIndustrialmmOuterPrecisionSNRSpeed
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
SNR 6228 C3F25 DEEP GROOVE BALL BEARING
The SNR 6228 C3F25 is a precision-engineered deep groove ball bearing designed for heavy-duty industrial applications. With C3 radial clearance, high load capacity, and excellent speed limits, this bearing ensures durability and reliable performance in demanding environments.
Manufacturer: SNR
Type: Deep Groove Ball Bearing
Model: 6228 C3F25
| Bore Diameter (d) | 140 mm |
| Outer Diameter (D) | 250 mm |
| Width | 42 mm |
| Radial Clearance Class | C3 |
| Dynamic Load | 184 kN |
| Static Load | 150 kN |
| Fatigue Limit Load | 8.4 kN |
| Oil Lubrication Limit Speed | 2900 tr/min |
| Grease Lubrication Limit Speed | 2500 tr/min |
