Southocean GX-1 MAX 1000 KG Shear Beam Load Cell

Available on request

150,00$

Manufacturer
SOUTHOCEAN
SKU
970890
Category
Load Cells
Condition
New
Share
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed

Manufacturer: SOUTHOCEAN

Type: Shear Beam Load Cell

Model: GX-1

Features

  • Self-Centering, Simple to Install, Easy to Use, Diverse Loading.
  • One End Fixed, Good Seal Structure.
  • Materials:
  • Alloy Steel
  • Stainless Steel
  • Fully Welded (IP68)

Application

  • Suitable for Various Ultrathin Electronic Truck Scale, One Truck Crane Scale, Hopper Scale, Etc
  • Weighs Axes
  • Hoppers
  • Weighing Platforms

Maximum weight limit (E max): 1000 kg

Nominal Output:
3.0052 mV/V

Nominal Supply Voltage:
10 V

Input Resistance:
385±10% Ω

Output Resistance:
350±3% Ω

Nominal Temperature:
-10…40 °C

Cable Length:
6 m

Protection Class:
IP68

Weight: 0.980 kg
