Sprecher+Schuh LA 2-25-7303 Reversing Switch
New
In stock3 unitsReady to ship
49,99$
Reversing Switch / Rotary Cam Switch
The Sprecher+Schuh / Breter LA2-25-7303 is a robust reversing switch with 25 A thermal current and a wide switching voltage range. It is built for high power consumption and a broad operating temperature range, making it ideal for industrial electrical applications.255.5-13690947-3aACCamConsumptionCurrentIECIndustrialkWLA2-25-7303PowerReversingRotarySprecher+SchuhSwitchThermalV
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Sprecher+Schuh / Breter LA2-25-7303 “ Reversing Switch / Rotary Cam Switch
The Sprecher+Schuh / Breter LA2-25-7303 reversing switch offers reliable performance in industrial electrical applications. Designed to handle high voltages and power consumption, it is built to operate efficiently within a wide temperature range, making it an ideal choice for heavy-duty electrical circuits.
Manufacturer: Sprecher+Schuh / Breter
Type: Reversing Switch / Rotary Cam Switch
Model: LA2-25-7303
Art. No.: 14.118.373.03
Power Consumption:
5.5 kW (220 V AC)
11 kW (380 V AC)
13 kW (500 V AC)
| Thermal Current Ith | 25 A |
| Rated Insulation Voltage Ui | 690 V AC |
| Switching Rating AC22A | 660 V AC, 25 A |
| Frequency | 50/60 Hz |
| Standard | IEC 947-3, VDE 0660 |
| Switching Angle | 1-0-2 (45 degrees) |
| Poles Switch | 3/3 |
| No. of Poles | 3 |
| Operating Temperature | -25 to 60°C |
