Steyr NU 2308 E/MA6/C3 Cylindrical Roller Bearing
New
In stock3 unitsReady to ship
Cylindrical Roller Bearing
The Steyr NU 2308 E/MA6/C3 is a precision cylindrical roller bearing with a 40 mm bore, machined brass cage (MA), and C3 clearance. Suitable for high radial loads and speeds up to 9300 rpm.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Steyr NU 2308 E/MA6/C3 Cylindrical Roller Bearing
The Steyr NU 2308 E/MA6/C3 Cylindrical Roller Bearing is engineered for high-load radial applications, featuring a machined brass cage (MA) located on the outer ring for enhanced stability and durability. With a C3 internal clearance, it allows for thermal expansion in high-speed or high-temperature environments, making it ideal for demanding industrial systems.
Manufacturer: Steyr
Type: Cylindrical Roller Bearing
Model: NU 2308 E/MA6/C3
| Bore Diameter (d) | 40 mm |
| Outer Diameter (D) | 90 mm |
| Width | 33 mm |
| Dynamic Load Rating | 128000 N |
| Static Load Rating | 118000 N |
| Limiting Speed (Grease) | 8000 rpm |
| Limiting Speed (Oil) | 9300 rpm |
| Cage Type | MA, Machined Brass Cage (located on outer ring) |
| Radial Internal Clearance | C3 |
