Telemecanique CA3 DN22BD Control Relay
The TELEMECANIQUE CA3 DN22BD Control Relay features 600V AC max. voltage, 10 A thermal current, 8 kV impulse-withstand voltage, and 3-pole configuration, ensuring reliable control in industrial circuits.
TELEMECANIQUE CA3 DN22BD Control Relay
The TELEMECANIQUE CA3 DN22BD Control Relay is a high-quality control relay designed for industrial applications. With a robust voltage rating and reliable protection, this relay ensures safe and efficient operation in controlling circuits and machinery in a variety of industrial environments.
- Manufacturer: TELEMECANIQUE
- Type: Control Relay
- Model: CA3 DN22BD
Technical Specifications:
- Voltage Max.: 600V AC
- Rated Insulation Voltage (Ui): 1000 V
- Thermal Current (Ith): 10 A
- Rated Impulse-Withstand Voltage (Uimp): 8 kV
- Number of Poles: 3 poles
- Contact: 2 Normally Open (NO), 2 Normally Closed (NC)
- Degree of Protection: IP20
- Frequency: 50/60 Hz
The TELEMECANIQUE CA3 DN22BD Control Relay offers high insulation voltage, thermal current rating, and impulse-withstand voltage, making it an ideal choice for use in demanding industrial circuits. With 3 poles and multiple contact configurations, it provides versatile and reliable switching operations for control and protection.
