Telemecanique LP2-EC 09 Contactor

Telemecanique LP2-EC09 Contactor

The **Telemecanique LP2-EC09 Contactor** is a reliable switching device for industrial and commercial applications. It features 3 poles and is designed for high performance, with a 660V insulation voltage and 16A thermal current rating. Suitable for controlling motors, it supports up to **1.5 hp** at 200“230V AC and **3 hp** at 460“575V AC.

Manufacturer: TELEMECANIQUE

Type: Contactor

Model: LP2-EC09

Technical Data:

• No. of Poles: 3
• Insulation Voltage: 660 V
• Thermal Current: 16 A
• Power Consumption:
  • 1.5 hp (200“230 V AC, 3 ph)
  • 3 hp (460“575 V AC, 3 ph)
• Torque: 7 lb.in
